Chip Gallery
9-to-37GHz Ultra-Wideband LO Generator
28GHz Compact yet Highly Efficient FEM
AI-Assisted DCO Design Automation
D-band TX Array with High DC-to-EIRP Efficiency
Miniaturized Magnetic Neural Stimulator
Ultrasonic Transceiver for Non-Invasive ICP Sensing
47GHz Four-Way Doherty PA
Designer: Xiaohan Zhang, Hao Guo
GF 45nm CMOS SOI, Mar. 2023
Publication: ISSCC 2024 Lewis Winner Award, JSSC 2024
86-105GHz LO Generator with 191.2dBc/Hz FoM
28GHz Antenna Subset Modulation (ASM) TX Array
38GHz Power-Combined Watt-Level Doherty PA
Pseudo-Resistor with Leakage Current Self-Compensation for Biopotential Amplifier
38GHz Three-Way Doherty PA for 5G NR OFDM
Designer: Xiaohan Zhang
GF 45nm CMOS SOI, Mar. 2021
Publication: RFIC 2022 Best Student Paper Finalist, JSSC 2023
5,376-Channel Neural Recording and Stimulation System
28GHz Hybrid-Beamforming TX with Spatial Notch Steering
Designer: Yaolong Hu, Xiaohan Zhang
GF 45nm CMOS SOI, Apr. 2020
Publication: CICC 2021 Best Student Paper, JSSC 2024
GHz Stacked Oscillator for Localized Heating of Magnetic Nanoparticles
PUF-Controlled PA Spectral Regrowth for RF Fingerprinting
Designer: Qiang Zhou, Yan He
GF 45nm CMOS SOI, Apr. 2020
Publication: ISSCC 2021, T-MTT 2024, ICC 2024
27-46GHz Broadband LNA
Designer: Yaolong Hu
GF 45nm CMOS SOI, Nov. 2019
Publication: MWCL 2021 (IMS Special Issue), T-CAS I 2023, MWTL 2023
